Madimack InverECLIPSE Plus Heat Pump Range
Madimack InverECLIPSE Plus Heat Pump Range
We sell below minimum advertised price. Inquire to request our best price.
Madimack InverECLIPSE Plus Heat Pump Range
Premium Vertical Inverter Heating with Market-Leading Warranties
The Madimack Eclipse Plus Series delivers top-tier heating performance in a compact vertical design—ideal for space-constrained areas and luxury pool settings. With twisted titanium heat exchangers, full stepless DC compressors, and operating range down to -10°C, it ensures exceptional heating efficiency and quiet operation even in challenging conditions. With heating capacities from 16.5kW to 26.0kW, it’s perfect for medium to large residential pools.
Each unit is protected by 25 years warranty on the heat exchanger, 5 years on the compressor, and 1 year on parts. Available now from Premium Pool Equipment with expert support, fast local dispatch, and certified installation services for Perth customers.
Key Features
- Vertical design – ideal for tight or narrow spaces
- Powerful inverter technology with full stepless DC compressor
- Rated to perform down to -10°C ambient conditions
- Twisted titanium heat exchanger for maximum efficiency
- Silent operation from as low as 41.2 dB(A)
- Long-term durability with market-leading warranties
Model Comparison Table
| Model | Heating Capacity (kW) | COP Range | Cooling Capacity (kW) | Max Input Current (A) | Water Flow (L/min) | Sound @1m (dB) | Dimensions (mm) | Net Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| ETD+ 160 | 16.5 | 15.2 ~ 7.2 | 7.3 | 13.5 | 120 | 41.2 ~ 54.9 | 780×710×656 | 70 |
| ETD+ 210 | 21.0 | 15.9 ~ 7.0 | 9.0 | 17.0 | 125 | 42.8 ~ 54.7 | 780×710×656 | 77 |
| ETD+ 260 | 26.0 | 15.0 ~ 6.9 | 11.2 | 20.0 | 150 | 41.5 ~ 55.2 | 780×710×756 | 88 |
*Performance data based on Air 27°C / Water 27°C / Humidity 80%. Refer to datasheet for full test conditions.
Electrical Connection
The Madimack Eclipse Plus ETD+ 160 model is equipped with a 15A plug for simplified installation, making it suitable for standard residential power outlets. The larger ETD+ 210 and ETD+ 260 models, however, require hardwired electrical connections and must be installed by a licensed electrician in accordance with Australian standards.
Recommended Pool Sizes
Choosing the correct heat pump depends on factors like pool volume, location, climate, and whether the pool is covered. The table below outlines recommended general maximum pool sizes for each InverEclipse Plus model under typical Australian conditions using a pool cover. If your pool is exposed, shaded, or located in cooler regions, consider sizing up for better performance.
| Model | Recommended Pool Size (Litres) |
|---|---|
| ETD+ 160 | Up to 35,000 L |
| ETD+ 210 | Up to 45,000 L |
| ETD+ 260 | Up to 55,000 L |
Frequently Asked Questions
Q: Is the Madimack InverEclipse Plus a gas or electric heat pump?
A: This is a fully electric inverter heat pump. It uses electricity to efficiently draw heat from the surrounding air and transfer it into your pool water, offering exceptional energy savings and consistent performance in most Australian climates.
Q: What makes the InverEclipse Plus different from other Madimack heat pumps?
A: The InverEclipse Plus combines ultra-modern design with market-leading inverter technology and an ultra-quiet stepless DC compressor. It also features a slimline cabinet and sleek LED touchscreen, making it a stylish and compact solution for premium pool heating.
Q: Can I install this heat pump indoors or in an enclosed area?
A: This heat pump is designed for outdoor installation with adequate airflow. Installing in a confined space may restrict airflow and reduce performance. Always follow Madimack’s installation guidelines or consult a certified installer.
Q: Is the InverEclipse Plus suitable for colder climates or year-round heating?
A: Yes, this unit operates in temperatures as low as -10°C and maintains excellent efficiency across all seasons. It's suitable for year-round heating and is one of the best choices for colder regions when correctly sized.
Q: Do I need a pool cover to use this heat pump effectively?
A: While not strictly required, a thermal pool cover significantly improves heating efficiency, retains warmth overnight, and reduces running costs. Recommended for all installations.
Q: How much energy does the unit consume?
A: Energy consumption varies by model and usage. For example, the ETD+ 160 has a rated input range of 0.38–2.33 kW, while the ETD+ 260 ranges from 0.84–3.91 kW. This means the unit adjusts energy use based on demand, making it far more efficient than older-style heaters.
Q: What kind of maintenance is required?
A: Very little. These units require occasional cleaning of the fan intake and visual inspection. No internal servicing is needed unless advised by a technician. Madimack also offers robust warranty support and service options.
Q: Is the unit noisy when operating?
A: Not at all. The InverEclipse Plus is one of the quietest units available, with sound levels as low as 41.2 dB. This makes it ideal for residential areas where noise is a concern.
Q: Can I control the unit remotely?
A: Yes. The InverEclipse Plus includes smart WiFi control as standard, allowing you to adjust temperature and settings via the Madimack app on your smartphone.
