Hayward SwimClear Quad-Cluster Cartridge Filters
High-Performance Cartridge Filtration Without the Hassle
The Hayward SwimClear Quad-Cluster Cartridge Filters offer powerful filtration for larger residential pools without the water waste and hassle of backwashing. Designed with four reusable cartridges and a massive surface area, these filters remove fine debris and maintain crystal-clear water with longer intervals between cleanings. They’re built tough for Australian conditions with a durable injection-moulded tank and simple installation.
Available in a range of sizes from 225 to 525 square feet, each unit includes a 5-year tank warranty and 1-year labour cover for peace of mind. Supplied by Premium Pool Equipment with local support and fast WA dispatch options available.
Key Features
- Quad-cartridge design for extended cleaning cycles
- Massive surface area for finer filtration and lower pressure loss
- No backwashing – saves thousands of litres of water annually
- Durable injection-moulded tank construction for longevity
- Compatible with high-performance pumps and automation systems
Model Comparison Table
| Model | Filtration Area (ft² / m²) |
Design Flow Rate (L/min) |
Clearance for Head Removal |
8-Hour Turnover (litres) |
10-Hour Turnover (litres) |
Shipping Weight |
Warranty |
|---|---|---|---|---|---|---|---|
| C2030 | 225 / 20.9 | 318 | 15” | 273,600 | 342,000 | 50lbs | 3Y Parts / 1Y Labour |
| C3030 | 325 / 30.2 | 462 | 16” | 363,360 | 454,200 | 60lbs | 3Y Parts / 1Y Labour |
| C4030 | 425 / 39.5 | 568 | 18” | 454,080 | 567,600 | 69lbs | 3Y Parts / 1Y Labour |
| C5030 | 525 / 48.8 | 568 | 22” | 545,280 | 681,600 | 79lbs | 3Y Parts / 1Y Labour |
*Turnover volumes based on maximum flow rate operating continuously over 8 or 10 hours. Maximum working pressure is 50 PSI (3.45 BAR).
Frequently Asked Questions
Q1: Do these filters require backwashing?
No — SwimClear filters use cartridge elements and do not require backwashing. Simply hose down the cartridges when needed.
Q2: How often do the cartridges need to be cleaned?
With proper sizing, cartridges can go several months between cleanings depending on conditions. Check more regularly during peak season.
Q3: What size should I choose for my pool?
It depends on pool volume and pump flow rate. For assistance, feel free to contact our support team with your setup details.
