Reltech Premium PR Series Pool Pump
We sell below minimum advertised price. Inquire to request our best price.
Description
Reltech Premium PR Series Pool & Spa Pump
Australian-made flagship pump engineered for quiet, energy-efficient performance
The Reltech Premium PR Series is the flagship single-speed pool and spa pump in Reltech’s Australian-made range, engineered for high water flow and powerful performance with low-noise, energy-efficient operation. Reltech designs its own electric motors specifically for these pumps, with a matched motor and pump wet-end optimised for quiet running, rapid priming and reliable performance year after year.
A computer-designed impeller and diffuser deliver a free, even flow, while the totally enclosed fan-cooled motor with built-in thermal overload protects against overheating. Every PR pump is factory pressure- and performance-tested, fitted with a high-performance silicon carbide mechanical seal for long life in salt and fresh water, and built from corrosion- and UV-resistant materials. Available in six power ratings from 0.5HP to 2.0HP — every model runs on a standard 240V / 10A power point — with noise levels from a class-leading 55 dB(A) on the smallest model.
Key Features
- Australian made – Reltech’s flagship single-speed pool & spa pump.
- High flow at high pressure – computer-designed impeller and diffuser for rapid priming and pool water turnover.
- Whisper-quiet operation – noise ratings from 55 to 65 dB(A) @ 1 m depending on model.
- Continuous-duty enclosed fan-cooled motor with built-in thermal overload protection.
- High-performance silicon carbide mechanical seal – durable in salt and fresh water.
- Extra-large strainer basket with see-through lid for easy debris removal and longer cleaning intervals.
- ABS quick-connect barrel unions – accept 40 mm pipe ID or 50 mm fitting ID PVC pressure pipe.
- Standard 240V / 10A 3-pin plug across the entire PR range — no dedicated 15A circuit required.
- Corrosion- and UV-resistant construction; designed to AS 3633, AS 1926.3 and AS 3000.
- Pressure- and performance-tested in factory; 2 m fitted power lead.
- 3-year limited warranty (residential).
Sizes Available
- PR50 – 0.50HP, 160 LPM, 55 dB(A) — small pools and spas
- PR75 – 0.75HP, 190 LPM, 58 dB(A) — small to mid-size pools
- PR100 – 1.00HP, 270 LPM, 60 dB(A) — mid-size residential pools
- PR125 – 1.25HP, 330 LPM, 62 dB(A) — mid to large residential pools
- PR150 – 1.50HP, 380 LPM, 63 dB(A) — large residential pools
- PR200 – 2.00HP, 490 LPM, 65 dB(A) — large residential / light commercial pools
Warranty
| Component | Residential Warranty | Commercial Warranty |
|---|---|---|
| Pump Body | 3 Years | 6 Months (parts & in-field labour*) |
| Motor, O-rings, Lid, Lid Nut, Impeller & Diffuser | 2 Years | 6 Months (parts & in-field labour*) |
| Mechanical Seal | 12 Months | 6 Months |
| In-Field Labour | 12 Months* | 6 Months* |
*In-field labour warranty applies in capital city metropolitan areas or within a 20 km radius of an Authorised Reltech Service Agent. Travel and freight charges may apply outside these areas. Replacement of routine maintenance items (O-rings, gaskets, seals, bearings) is not covered. Refer to Reltech’s official Limited Warranty Terms and Conditions for full details.
Model Comparison Table
| Model | Horsepower | Flow Rate (LPM @ 8 m head) | Watts (W) | Full Load Amps | Noise dB(A) | Pump Length (mm) | Pipe Connection | Power Supply |
|---|---|---|---|---|---|---|---|---|
| PR50 | 0.50HP | 160 | 690 | 2.98 | 55 | 610 | 40 / 50 mm | 240V / 10A |
| PR75 | 0.75HP | 190 | 733 | 3.30 | 58 | 610 | 40 / 50 mm | 240V / 10A |
| PR100 | 1.00HP | 270 | 883 | 4.00 | 60 | 620 | 40 / 50 mm | 240V / 10A |
| PR125 | 1.25HP | 330 | 980 | 4.44 | 62 | 620 | 40 / 50 mm | 240V / 10A |
| PR150 | 1.50HP | 380 | 1205 | 6.10 | 63 | 630 | 40 / 50 mm | 240V / 10A |
| PR200 | 2.00HP | 490 | 1850 | 8.60 | 65 | 665 | 40 / 50 mm | 240V / 10A |
*Flow rates measured at 8 m total dynamic head. All models run at 2,850 RPM on 50 Hz, IPX5 rated. All specifications acquired from the official Reltech Premium PR Series Manual and 2024 product brochure.
Reltech Premium PR Series Pool & Spa Pump
Australian-made flagship pump engineered for quiet, energy-efficient performance
The Reltech Premium PR Series is the flagship single-speed pool and spa pump in Reltech’s Australian-made range, engineered for high water flow and powerful performance with low-noise, energy-efficient operation. Reltech designs its own electric motors specifically for these pumps, with a matched motor and pump wet-end optimised for quiet running, rapid priming and reliable performance year after year.
A computer-designed impeller and diffuser deliver a free, even flow, while the totally enclosed fan-cooled motor with built-in thermal overload protects against overheating. Every PR pump is factory pressure- and performance-tested, fitted with a high-performance silicon carbide mechanical seal for long life in salt and fresh water, and built from corrosion- and UV-resistant materials. Available in six power ratings from 0.5HP to 2.0HP — every model runs on a standard 240V / 10A power point — with noise levels from a class-leading 55 dB(A) on the smallest model.
- Australian made – Reltech’s flagship single-speed pool & spa pump.
- High flow at high pressure – computer-designed impeller and diffuser for rapid priming and pool water turnover.
- Whisper-quiet operation – noise ratings from 55 to 65 dB(A) @ 1 m depending on model.
- Continuous-duty enclosed fan-cooled motor with built-in thermal overload protection.
- High-performance silicon carbide mechanical seal – durable in salt and fresh water.
- Extra-large strainer basket with see-through lid for easy debris removal and longer cleaning intervals.
- ABS quick-connect barrel unions – accept 40 mm pipe ID or 50 mm fitting ID PVC pressure pipe.
- Standard 240V / 10A 3-pin plug across the entire PR range — no dedicated 15A circuit required.
- Corrosion- and UV-resistant construction; designed to AS 3633, AS 1926.3 and AS 3000.
- Pressure- and performance-tested in factory; 2 m fitted power lead.
- 3-year limited warranty (residential).
- PR50 – 0.50HP, 160 LPM, 55 dB(A) — small pools and spas
- PR75 – 0.75HP, 190 LPM, 58 dB(A) — small to mid-size pools
- PR100 – 1.00HP, 270 LPM, 60 dB(A) — mid-size residential pools
- PR125 – 1.25HP, 330 LPM, 62 dB(A) — mid to large residential pools
- PR150 – 1.50HP, 380 LPM, 63 dB(A) — large residential pools
- PR200 – 2.00HP, 490 LPM, 65 dB(A) — large residential / light commercial pools
| Component | Residential Warranty | Commercial Warranty |
|---|---|---|
| Pump Body | 3 Years | 6 Months (parts & in-field labour*) |
| Motor, O-rings, Lid, Lid Nut, Impeller & Diffuser | 2 Years | 6 Months (parts & in-field labour*) |
| Mechanical Seal | 12 Months | 6 Months |
| In-Field Labour | 12 Months* | 6 Months* |
*In-field labour warranty applies in capital city metropolitan areas or within a 20 km radius of an Authorised Reltech Service Agent. Travel and freight charges may apply outside these areas. Replacement of routine maintenance items (O-rings, gaskets, seals, bearings) is not covered. Refer to Reltech’s official Limited Warranty Terms and Conditions for full details.
| Model | Horsepower | Flow Rate (LPM @ 8 m head) | Watts (W) | Full Load Amps | Noise dB(A) | Pump Length (mm) | Pipe Connection | Power Supply |
|---|---|---|---|---|---|---|---|---|
| PR50 | 0.50HP | 160 | 690 | 2.98 | 55 | 610 | 40 / 50 mm | 240V / 10A |
| PR75 | 0.75HP | 190 | 733 | 3.30 | 58 | 610 | 40 / 50 mm | 240V / 10A |
| PR100 | 1.00HP | 270 | 883 | 4.00 | 60 | 620 | 40 / 50 mm | 240V / 10A |
| PR125 | 1.25HP | 330 | 980 | 4.44 | 62 | 620 | 40 / 50 mm | 240V / 10A |
| PR150 | 1.50HP | 380 | 1205 | 6.10 | 63 | 630 | 40 / 50 mm | 240V / 10A |
| PR200 | 2.00HP | 490 | 1850 | 8.60 | 65 | 665 | 40 / 50 mm | 240V / 10A |
*Flow rates measured at 8 m total dynamic head. All models run at 2,850 RPM on 50 Hz, IPX5 rated. All specifications acquired from the official Reltech Premium PR Series Manual and 2024 product brochure.
Frequently Asked Questions
Q1: How do I choose the right HP for my pool?
Match the model to your pool size, filter rating and pipework. As a general guide, the PR50 and PR75 suit small pools and spas, the PR100 and PR125 suit most standard residential pools, and the PR150 and PR200 are recommended for large residential or light commercial installations. If you’re replacing an existing Reltech, Astral, Hurlcon or Onga pump, match the HP rating directly — or contact us for sizing advice.
Q2: Is the PR Series compatible with salt water and chlorinators?
Yes. The PR Series is fitted with a high-performance silicon carbide mechanical seal designed for long life in both salt and fresh water, and is designed to operate with most chlorinators, heaters and other pool equipment.
Q3: What pipe size do I need?
The ABS quick-connect barrel unions accept 40 mm pipe ID or 50 mm fitting ID PVC pressure pipe on both inlet and outlet. Smaller-ID piping is not recommended and may damage the pump and void warranty. A straight section of pipe at least 300 mm long should be installed before the inlet for smoother, quieter operation.
Q4: What power supply do I need?
The entire PR Series runs on a standard 240V / 10A 3-pin plug — no dedicated 15A circuit is required, even on the PR200 (2.0HP). All units come with a 2 m fitted power lead. Reltech recommends installation behind a residual current device (RCD) with a rated residual operating current not exceeding 30 mA.
Q5: Does the PR200 require any special installation?
Yes — Reltech recommends fitting a check valve in the suction line of the PR200 (2.0HP) to prevent back-pressure issues that can cause a back-spun impeller. This is a manufacturer requirement and back-spin damage is not covered under warranty. Any pump installed above pool water level also requires a check valve.
Q6: How does this compare to the Reltech Platinum PLT Series?
The PR Series is Reltech’s premium high-performance flagship, available in six sizes from 0.5HP to 2.0HP and running on a standard 10A plug throughout. The Platinum PLT Series is built for very large pools and commercial applications, available from 1.0HP to 3.0HP (the PLT300 requires a 15A circuit). For maximum energy savings, ask us about the Reltech Ecoflo Variable-Speed range, which carries up to 8-star MEPS efficiency ratings.
Q7: Are these pumps suitable for commercial use?
Yes. The PR Series is designed for both residential pools and commercial pools and spas including motels, hotels, health clubs and hydrotherapy applications. Note that commercial installations carry a shorter warranty period (6 months parts and in-field labour) — see the warranty table for full terms.
